Description
MULTIPRO TIG 220AD G-JBT INVERTER 200A AC/DC TIG & MMA 220V DIGITAL DISPLAY
Spesifikasi:
Input Voltage: 1ph 220 V ± 15%
Frequency: 50 / 60 Hz
No-load Voltage: 65 VDC
Rated Input Power: TIG : 5.0 KVA; MMA :6.0 KVA
Rated Input Current: TIG : 22 A ;MMA :25 A
Rated Working Voltage: TIG : 16.4 V
MMA :25.6 V
Range Of Output Current: TIG : 5~200 A; MMA :10~160 A
Arc Force Current Range: 0 – 40
Rated Duty Cycle: 60%
Power Factor: ≥0.89
Efficiency: ≥85%
Insulation Type: B
Protection Type: IP21S
Pulse Frequency: 0.2~200 Hz
Pulse Duty: 10~90 %
Arc Starting: HF
AC Frequency: 20~250 Hz
AC Balance: 20~80 %
Up Slope: 0~10 S
Down Slope: 0~15 S
Post-Flow Time: 0.5~15 S
Pre-Flow Time:0.1~10 S
Weight:9 Kg
MULTIPRO TIG 220AD G-JBT INVERTER 200A AC/DC TIG & MMA 220V DIGITAL DISPLAY
Spesifikasi:
Input Voltage: 1ph 220 V ± 15%
Frequency: 50 / 60 Hz
No-load Voltage: 65 VDC
Rated Input Power: TIG : 5.0 KVA; MMA :6.0 KVA
Rated Input Current: TIG : 22 A ;MMA :25 A
Rated Working Voltage: TIG : 16.4 V
MMA :25.6 V
Range Of Output Current: TIG : 5~200 A; MMA :10~160 A
Arc Force Current Range: 0 – 40
Rated Duty Cycle: 60%
Power Factor: ≥0.89
Efficiency: ≥85%
Insulation Type: B
Protection Type: IP21S
Pulse Frequency: 0.2~200 Hz
Pulse Duty: 10~90 %
Arc Starting: HF
AC Frequency: 20~250 Hz
AC Balance: 20~80 %
Up Slope: 0~10 S
Down Slope: 0~15 S
Post-Flow Time: 0.5~15 S
Pre-Flow Time:0.1~10 S
Weight:9 Kg
Dimension (LxWxH):410x160x265
