WESTLAKE ZQ 4116/I NEW BENCH DRILLING MACHINE 16MM

WESTLAKE ZQ 4116/I NEW BENCH DRILLING MACHINE 16MM

Spesifikasi:

Max. Drilling Capacity : 16 mm

Diameter Of Column : 72 mm

Spindel Travle : 85 mm

Distance Spindle Axis To Column Surface : 160 mm

Distance Spindle Nose To Worktable : 450 mm

Distance Spindle Nose To Base : 630 mm

Spindle Taper : MT2

Spindle Speeds Range : 180 – 2770 r/min

Spindle Speeds : 16

Dimension Of Worktable : 290 mm

Dimension Of Base : 420 x 250 mm

Overal Height : 980 mm

Motor Power : 370 watt

Warranty: No
