MULTIPRO INA 125 A-MZ SMAW/MMA DC IGBT INVERTER WELDER MACHINE 120A 220V 3KVA

Description

MULTIPRO INA 125 A-MZ SMAW/MMA DC IGBT INVERTER WELDER MACHINE 120A 220V 3KVA

Spesifikasi:
Input Voltage : 1ph 220V ± 15%
Frequency : 50 / 60 Hz
Rated Input Power : 3 KVA
Range Working Voltage : 24 V
No-load Voltage : 66 V
Range of Output Current : 24 A
Rated Input Current : 13.8 V
Diameter of Electrode : ø 0.2 ~ 3.2 mm
Rated Duty Cycle : 60%
Power Factor : ≥ 0.99
Efficiency : ≥ 85%
Insulation Type : B
Protection Type : IP21
Weight : 2.15 Kg
Dimension : 230 x 110 x 175 mm
IGBT Type : Single Tube

STANDARD ACCESSORIES
Electrode Holder Set
Earth Clamp Set
Wire Brush/Chipping Hammer
Hand Shield
